Yaskawa 619bebd72f1b9

Five-Axis Robot

Nov. 22, 2021
Yaskawa America Motoman Robotics Division's PL80 Robot excels at case palletizing, bag palletizing, de-palletizing, layer picking, and layer forming.

Ideal for a variety of palletizing applications, order picking, and other logistical tasks for end-of-line or distribution automation, the PL80 Robot excels at case palletizing, bag palletizing, de-palletizing, layer picking, and layer forming.

Featuring a 176.4 lb (80 kg) payload capacity, the reliable robot offers a 81.1 in. (2,061 mm) horizontal reach and a 129.6 in. (3,291 mm) vertical reach.

Optimizing production throughput over conventional methods, the robot's wide working range and performance-driven design features fast axis speeds and acceleration capabilities. It has an IP67-rated wrist and an IP54 body as standard.

A single cable is all that is needed to connect the manipulator to the controller, resulting in easy setup and reduced expenses for maintenance and spare parts inventory. Airlines and cables are routed internally from the base to the end-of-arm tool to maximize reliability, and a cable installation tube facilitates fieldbus routing to the upper arm and/or gripper.

The robot can be floor-mounted, and brakes are included on all axes. The robot is controlled by the high-performance YRC1000 controller that is built to a global standard and does not require a transformer for input voltages ranging from 380AC to 480VAC.

Yaskawa America, Inc., Motoman Robotics Division
